DTV
Fine Pitch Smart TV
■ Cable-free connection
■ Simple operation, plug and play
■ Easy for setup and dismantle
HD ULTRA HIGH DEFINITION PICTURE QUALITY
To make the picture more real and natural,Every detail is clearly visible.
2K/4K HD display picture quality
HD standard golden display ratio 16:9
Easy to operate and display
Support for adaptive display and multiple screens
High refresh and grey scale
The display is ultra-realistic,with a refresh rate up to 3840hz
Creatative design of light weight and thin
Ultra weight 5kgs , Ultra thin 38mm
Different HD screen
136"/162" Large size
160° Wide angle
1920*1080 Resolution
38mm Ultra thin
Technical parameters
| Item | T136 | T162 |
| Screen size | 136" | 162" |
| Pixel pitch | 1.56mm | 1.87mm |
| Screen resolution | 1920*1080pixels | 1920x1080pixels |
| Brightness | 600nits | 600nits |
| Scanning mode | Constant current | Constant current |
| Working environment | indoor | indoor |
| Viewing angle | H/V:160° | H/V:160° |
| Cabinet resolution | 384 x 216pixels | 320 x 180pixels |
| Waterproof level | IP34 | IP34 |
| Average power | 225w/sqm | 225w/sqm |
| Refresh rate | ≤3840Hz | ≤3840Hz |
| Screen size | 3000 x 1687.5mm | 3600 x 2025mm |
| Screen Thickness | 38mm | 38mm |
| Scene application area | 100sqm | 150sqm |
| Attendance： | 50persons | 100persons |
